PT79SR105T
RoHS
RoHS compliant
RoHS compliantPackage 3-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC Converters -5Vout 1.5A Wide-Inp Neg Step-Down ISR
PDF
/
Inventory: 2153
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Length 22.6mm
Technical
Switcher Configuration BUCK
Current - Output 1 1.5A
Control Mode VOLTAGE-MODE
Topology Boost
Output Power 7.5W
Output Current 1.5A
Input Voltage-Nom -10V
Voltage - Input (Min) -9V
Max Output Current 1.5A
Output Voltage -5V
Voltage - Input (Max) -30V
Efficiency 85%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 3
Base Part Number 79SR105
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 23.9mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 7.5W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature OTP, SCP
Series PT79SR100
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 7g
Number of Pins 3
Package / Case 3-SIP Module
Mounting Type Through Hole
Mount Through Hole
