PT78ST115S

Texas Instruments
RoHS
RoHS RoHS compliant
Package 3-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description DC DC CONVERTER 15V 1.5A
PDF
/
Inventory: 3990
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Height 8.636mm

Technical

Isolation Non-Isolated
Switching Frequency-Max 700kHz
Switcher Configuration BUCK
Min Output Voltage 15V
Current - Output 1 1.5A
Control Mode VOLTAGE-MODE
Max Output Voltage 15V
Output Power 22.5W
Output Current 1.5A
Input Voltage-Nom 19V
Voltage - Input (Min) 19V
Max Output Current 1.5A
Output Voltage 15V
Voltage - Input (Max) 38V
Efficiency 90%
Number of Outputs 1
Base Part Number 78ST115
Current Rating 1.5A
Depth 22.86mm
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 22.5W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature OTP, SCP
Size / Dimension 0.94Lx0.90W x 0.34 H 23.9mmx22.9mmx8.6mm
Series PT78ST100
Packaging Tray
Operating Temperature -40°C~85°C

Physical

Number of Pins 3
Surface Mount YES
Package / Case 3-SMD Module
Mounting Type Surface Mount
