PT78ST115H
RoHS
RoHS compliant
RoHS compliantPackage 3-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REGULATOR 15VOUT 1.5A HORZ
PDF
/
Inventory: 1414
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole, Right Angle
Package / Case 3-SIP Module
Surface Mount NO
Number of Pins 3
Weight 6.5g
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series PT78ST100
Size / Dimension 0.94Lx0.90W x 0.31 H 23.9mmx22.9mmx7.9mm
Feature OTP, SCP
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
HTS Code 8504.40.85.00
Subcategory Switching Regulator or Controllers
Max Power Dissipation 22.5W
Technology HYBRID
Terminal Position SINGLE
Number of Functions 1
Terminal Pitch 2.54mm
Depth 23.62mm
Base Part Number 78ST115
Number of Outputs 1
Efficiency 90%
Voltage - Input (Max) 38V
Output Voltage 15V
Max Output Current 1.5A
Voltage - Input (Min) 19V
Input Voltage-Nom 19V
Output Current 1.5A
Output Power 22.5W
Max Output Voltage 15V
Control Mode VOLTAGE-MODE
Current - Output 1 1.5A
Min Output Voltage 15V
Switcher Configuration BUCK
Max Output Power 22.5W
Switching Frequency-Max 700kHz
Isolation Non-Isolated
Nominal Output Voltage 15V
Dimensions
Height 7.874mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
