PT78NR212ST
RoHS
RoHS compliant
RoHS compliantPackage 3-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REG SW 2A 12V POS STEP-DN SMD
PDF
/
Inventory: 5698
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 3-SMD Module
Surface Mount YES
Number of Pins 3
Technical
Operating Temperature 0°C~85°C
Packaging Tape & Reel (TR)
Series PT78NR200 (12W)
Size / Dimension 1.01Lx0.93W x 0.41 H 25.7mmx23.6mmx10.4mm
Feature OTP, SCP
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Subcategory Switching Regulator or Controllers
Max Power Dissipation 12W
Technology HYBRID
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 78NR212
Pin Count 3
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 78%
Voltage - Input (Max) 15V
Output Voltage -12V
Max Output Current 1A
Voltage - Input (Min) 9V
Input Voltage-Nom 10V
Output Current 1A
Output Power 12W
Max Output Voltage -12V
Topology Boost
Control Mode VOLTAGE-MODE
Current - Output 1 1A
Min Output Voltage -12V
Switcher Configuration SINGLE
Switching Frequency-Max 700kHz
Dimensions
Height 10.414mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
