PT78HT233V
RoHS
RoHS compliant
RoHS compliantPackage 3-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC Converters 3.3Vout 2A Wide-Inpt Pos Step-Down ISR
PDF
/
Buying Options
Total Price: USD $74.5
Unit Price: USD $74.4952
≥1 USD $74.4952
≥10 USD $72.16675
≥100 USD $69.83925
≥500 USD $67.5108
≥1000 USD $60.52735
Inventory: 1156
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 23.876mm
Technical
Isolation Non-Isolated
Switcher Configuration BUCK
Min Output Voltage 3.3V
Current - Output 1 2A
Control Mode VOLTAGE-MODE
Max Output Voltage 3.3V
Output Power 6.6W
Output Current 2A
Input Voltage-Nom 9V
Voltage - Input (Min) 9V
Max Output Current 2A
Output Voltage 3.3V
Voltage - Input (Max) 15V
Efficiency 80%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 3
Base Part Number 78HT233
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 7.87mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 6.6W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature OTP, SCP
Size / Dimension 0.90Lx0.31W x 0.94 H 22.9mmx7.9mmx23.9mm
Series PT78HT200
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 3
Surface Mount NO
Package / Case 3-SIP Module
Mounting Type Through Hole
