PT78HT205T
RoHS
RoHS compliant
RoHS compliantPackage 3-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REGULATOR 2A 5V TAB MOUNT
PDF
/
Inventory: 9361
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case 3-SIP Module
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series PT78HT200
Feature OTP, SCP
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Technology HYBRID
Peak Reflow Temperature (Cel) 215
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 78HT205
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 85%
Voltage - Input (Max) 28V
Voltage - Output 1 5V
Voltage - Input (Min) 9V
Input Voltage-Nom 9V
Current - Output (Max) 2A
Switcher Configuration BUCK
Switching Frequency-Max 800kHz
Compliance
RoHS Status ROHS3 Compliant
