PT7779A
RoHS
RoHS compliant
RoHS compliantPackage 27-SIP Module, Horizontal
Category Power Supplies - Board Mount / DC DC Converters
Description
Switching Converters, Regulators & Controllers PROGRAMMABLE ISR
PDF
/
Inventory: 5709
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Horizontal, Through Hole
Mounting Type Through Hole, Horizontal
Package / Case 27-SIP Module, Horizontal
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series PT7779
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 27
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Subcategory Switching Regulator or Controllers
Max Power Dissipation 112W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 27
JESD-30 Code R-XSMA-T27
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 90%
Voltage - Input (Max) 5.5V
Max Output Current 32A
Voltage - Output 1 1.3V~3.5V
Voltage - Input (Min) 4.5V
Input Voltage-Nom 5V
Control Mode VOLTAGE-MODE
Current - Output 1 32A
Nominal Input Voltage 5V
Switcher Configuration SINGLE
Switching Frequency-Max 400kHz
Dimensions
Height 48mm
Length 71.6mm
Width 12.7mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
