PT7775A
RoHS
RoHS compliant
RoHS compliantPackage 27-SIP Module, Horizontal
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 1-OUT 0.8V to 3.1V 32A 27-Pin SIP Module
PDF
/
Buying Options
Total Price: USD $195.94
Unit Price: USD $195.941993
≥1 USD $195.941993
≥10 USD $189.499029
≥25 USD $188.181755
≥50 USD $186.873635
≥100 USD $183.030006
≥500 USD $169.944296
Inventory: 1138
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Width 12.7mm
Length 71.37mm
Technical
Isolation Non-Isolated
Switching Frequency-Max 400kHz
Switcher Configuration BUCK
Current - Output 1 32A
Control Mode VOLTAGE-MODE
Output Current 32A
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Voltage - Output 1 0.8V~3.1V
Max Output Current 32A
Output Voltage 3.1V
Voltage - Input (Max) 5.5V
Efficiency 90%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 27
Base Part Number PT7775
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Depth 45.16mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 99.2W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 27
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series PT7770
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 27
Package / Case 27-SIP Module, Horizontal
Mounting Type Through Hole, Horizontal
Mount Horizontal, Through Hole
