PT7769N
RoHS
RoHS compliant
RoHS compliantPackage 31-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 5VIN 1-OUT 1.3V to 3.5V 40A 31-Pin SIP Module
PDF
/
Buying Options
Total Price: USD $68.23
Unit Price: USD $68.2264
≥1 USD $68.2264
Inventory: 489
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Length 91.44mm
Technical
Isolation Non-Isolated
Switching Frequency-Max 400kHz
Switcher Configuration SINGLE
Output Current 40A
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Voltage - Output 1 1.3V~3.5V
Max Output Current 40A
Output Voltage 3.5V
Voltage - Input (Max) 5.5V
Efficiency 86%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 31
Base Part Number PT7769
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 16.26mm
Number of Functions 1
Peak Reflow Temperature (Cel) 215
Terminal Position SINGLE
Max Power Dissipation 140W
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 31
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Series Excalibur? PT7761
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 31
Package / Case 31-SIP Module
Mounting Type Through Hole
Mount Through Hole
