PT7748A
RoHS
/
Package 27-SIP Module, Horizontal
Category Power Supplies - Board Mount / DC DC Converters
Description
REGULATOR 15A 12V BOOSTER HORZ
PDF
/
Inventory: 2301
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Height 45.212mm
Technical
Switching Frequency-Max 400kHz
Switcher Configuration BOOST
Control Mode VOLTAGE-MODE
Input Voltage-Nom 12V
Voltage - Input (Min) 11V
Voltage - Output 1 11V~14V
Max Output Current 17A
Voltage - Input (Max) 14V
Efficiency 90%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-MSMA-T27
Pin Count 27
Base Part Number PT7748
Number of Functions 1
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 238W
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 27
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 2.81Lx0.49W x 1.78 H 71.4mmx12.5mmx45.1mm
Series PT7720
Packaging Tray
Operating Temperature 0°C~85°C
Physical
Package / Case 27-SIP Module, Horizontal
Mounting Type Through Hole, Horizontal
Mount Horizontal, Through Hole
