PT7746C
RoHS
/
Package 27-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REGULATOR CURNT BSTR HORZ 27SIP
PDF
/
Inventory: 2978
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 27-SMD Module
Technical
Operating Temperature 0°C~85°C
Series PT7740
Size / Dimension 2.81Lx1.78W x 0.49 H 71.4mmx45.2mmx12.5mm
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 27
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Max Power Dissipation 176W
Technology HYBRID
Terminal Position SINGLE
Terminal Form THROUGH-HOLE
Number of Functions 1
Base Part Number PT7746
Pin Count 27
JESD-30 Code R-XSMA-T27
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 90%
Voltage - Input (Max) 5.5V
Max Output Current 32A
Voltage - Output 1 3V~5.5V
Voltage - Input (Min) 3V
Trim/Adjustable Output NO
Dimensions
Height 12.446mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
