RoHS
/
Package 27-SIP Module, Vertical
Category Power Supplies - Board Mount / DC DC Converters
Description REGULATR 32A BSTR FOR PT7778 VRT
PDF
/
Inventory: 2392
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant

Dimensions

Height 45.212mm

Technical

Trim/Adjustable Output NO
Voltage - Input (Min) 3.1V
Voltage - Output 1 3.1V~3.6V
Max Output Current 32A
Voltage - Input (Max) 3.6V
Efficiency 90%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-XSMA-T27
Number of Functions 1
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 115.2W
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 27
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Size / Dimension 2.81Lx0.49W x 1.78 H 71.4mmx12.5mmx45.1mm
Series PT7740
Packaging Tray
Operating Temperature 0°C~85°C

Physical

Package / Case 27-SIP Module, Vertical
Mounting Type Through Hole, Vertical
Mount Through Hole, Vertical
