PT7716C
RoHS
RoHS compliant
RoHS compliantPackage 27-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Switching Converters, Regulators & Controllers 20A 1.075V-1.85V 3.3 Vin Programmable ISR
PDF
/
Inventory: 2794
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 12.7mm
Technical
Isolation Non-Isolated
Switching Frequency-Max 400kHz
Switcher Configuration SINGLE
Output Current 20A
Input Voltage-Nom 3.3V
Voltage - Input (Min) 3.1V
Voltage - Output 1 1.075V~1.85V
Max Output Current 20A
Output Voltage 1.85V
Voltage - Input (Max) 3.6V
Efficiency 84%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 27
Base Part Number PT7716
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 25.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 215
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 37W
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 27
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Size / Dimension 3.00Lx1.19W x 0.50 H 76.2mmx30.2mmx12.7mm
Series Excalibur? PT7716
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 27
Package / Case 27-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
