PT7715N
RoHS
RoHS compliant
RoHS compliantPackage 27-SIP Module, Vertical
Category Power Supplies - Board Mount / DC DC Converters
Description
REG SW 5VIN 20A PROG LV VERT
PDF
/
Inventory: 2368
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 25.908mm
Technical
Switching Frequency-Max 400kHz
Switcher Configuration SINGLE
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Voltage - Output 1 1.075V~1.85V
Max Output Current 20A
Voltage - Input (Max) 5.5V
Efficiency 82%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-MSMA-T27
Base Part Number PT7715
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) 215
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 37W
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 27
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Size / Dimension 3.00Lx0.66W x 1.02 H 76.2mmx16.8mmx25.9mm
Series Excalibur? PT7715
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Package / Case 27-SIP Module, Vertical
Mounting Type Through Hole, Vertical
Mount Through Hole, Vertical
Alternative Model
