PT7705N
RoHS
RoHS compliant
RoHS compliantPackage 27-SIP Module, Vertical
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC Converters PROGRAMMABLE ISR
PDF
/
Buying Options
Total Price: USD $141.64
Unit Price: USD $141.636541
≥1 USD $141.636541
≥10 USD $133.619381
≥100 USD $126.056021
≥500 USD $118.920773
≥1000 USD $112.189408
Inventory: 4637
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole, Vertical
Mounting Type Through Hole, Vertical
Package / Case 27-SIP Module, Vertical
Number of Pins 27
Technical
Operating Temperature 0°C~85°C
Packaging Tray
Series PT7705
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 27
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Subcategory Switching Regulator or Controllers
Max Power Dissipation 63W
Technology HYBRID
Terminal Position SINGLE
Number of Functions 1
Depth 13.2mm
Pin Count 27
Number of Outputs 1
Efficiency 89%
Voltage - Input (Max) 5.5V
Output Voltage 3.5V
Max Output Current 18A
Voltage - Output 1 1.3V~3.5V
Voltage - Input (Min) 4.5V
Input Voltage-Nom 5V
Output Current 18A
Control Mode VOLTAGE-MODE
Switcher Configuration SINGLE
Switching Frequency-Max 750kHz
Dimensions
Length 76.96mm
Width 13.2mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
