PT7681C
RoHS
/
Package 27-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REG 2-3.5V 30A 5VIN PROG SMD
PDF
/
Inventory: 9843
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Height 12.7mm
Technical
Switching Frequency-Max 350kHz
Switcher Configuration SINGLE
Control Mode VOLTAGE-MODE
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Voltage - Output 1 2V~3.5V
Max Output Current 30A
Voltage - Input (Max) 5.5V
Efficiency 90%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-MSMA-G27
Pin Count 27
Base Part Number PT7681
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 105W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 27
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Remote On/Off, OCP, OTP, SCP
Size / Dimension 3.00Lx1.19W x 0.50 H 76.2mmx30.2mmx12.7mm
Series Excalibur? PT7681
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Package / Case 27-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
