PT6944A
RoHS
RoHS compliant
RoHS compliantPackage 27-SIP Module, Horizontal
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 5VIN 2-OUT 3.3V/1.2V 6A 27-Pin SIP Module
PDF
/
Inventory: 8437
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 12.7mm
Technical
Isolation Non-Isolated
Switching Frequency-Max 400kHz
Switcher Configuration SINGLE
Control Mode VOLTAGE-MODE
Voltage - Output 2 1.2V
Output Current 6A
Current - Output (Max) 6A 6A
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Max Output Current 6A
Output Voltage 3.3V
Voltage - Input (Max) 5.5V
Efficiency 90%
Number of Outputs 2
Pin Count 27
Base Part Number PT6944
Depth 30.22mm
Number of Functions 1
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 27W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 27
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Size / Dimension 3.00Lx1.19W x 0.50 H 76.2mmx30.2mmx12.7mm
Series Excalibur? PT6940
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 27
Package / Case 27-SIP Module, Horizontal
Mounting Type Through Hole, Horizontal
Mount Horizontal, Through Hole
Alternative Model
