PT6941N
RoHS
RoHS compliant
RoHS compliantPackage 27-SIP Module, Vertical
Category Power Supplies - Board Mount / DC DC Converters
Description
Switching Converters, Regulators & Controllers 3.3V/2.5V 6A+6A 5V-In Dual Otpt ISR
PDF
/
Inventory: 7766
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Height 25.908mm
Technical
Switching Frequency-Max 400kHz
Switcher Configuration SINGLE
Nominal Input Voltage 5V
Current - Output 1 6A
Control Mode VOLTAGE-MODE
Voltage - Output 2 2.5V
Current - Output (Max) 6A 6A
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Max Output Current 6A
Output Voltage 3.3V
Voltage - Input (Max) 5.5V
Efficiency 92%
Qualification Status Not Qualified
Number of Outputs 2
Pin Count 27
Base Part Number PT6941
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 34.8W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 27
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Size / Dimension 3.00Lx0.66W x 1.02 H 76.2mmx16.8mmx25.9mm
Series Excalibur? PT6940
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Package / Case 27-SIP Module, Vertical
Mounting Type Through Hole
Mount Through Hole
