PT6935A
RoHS
RoHS compliant
RoHS compliantPackage 23-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 2-OUT 2.5V/1.8V 11A 23-Pin SIP Module
PDF
/
Buying Options
Total Price: USD $537.82
Unit Price: USD $537.82255
≥1 USD $537.82255
Inventory: 309
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole, Right Angle
Package / Case 23-SIP Module
Number of Pins 23
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series Excalibur? PT6935
Size / Dimension 2.58Lx1.02W x 0.43 H 65.5mmx25.9mmx10.9mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 23
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Subcategory Switching Regulator or Controllers
Max Power Dissipation 30W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 25.65mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PT6935
Pin Count 23
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 79%
Voltage - Input (Max) 5.5V
Output Voltage 2.5V
Max Output Current 3.5A
Voltage - Input (Min) 3.1V
Input Voltage-Nom 5V
Current - Output (Max) 9.5A 3.5A
Output Current 11A
Voltage - Output 2 1.8V
Control Mode VOLTAGE-MODE
Current - Output 1 11A
Nominal Input Voltage 3.3V
Switcher Configuration SINGLE
Switching Frequency-Max 400kHz
Dimensions
Height 10.922mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
