PT6932A
RoHS
RoHS compliant
RoHS compliantPackage 23-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 5VIN 2-OUT 3.3V/1.5V 6A/1.45A 23-Pin SIP Module
PDF
/
Inventory: 4421
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 10.922mm
Technical
Switcher Configuration SINGLE
Control Mode VOLTAGE-MODE
Voltage - Output 2 1.5V
Output Power 25W
Output Current 6.95A
Current - Output (Max) 6A 1.45A
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Max Output Current 1.45A
Output Voltage 3.3V
Voltage - Input (Max) 5.5V
Efficiency 75%
Number of Outputs 2
Pin Count 23
Base Part Number PT6932
Number of Functions 1
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 22W
Power Rating 25W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 23
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Size / Dimension 2.58Lx1.19W x 0.43 H 65.5mmx30.2mmx10.9mm
Series Excalibur? PT6930
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 23
Package / Case 23-SIP Module
Mounting Type Through Hole, Right Angle
Mount Through Hole
