PT6921A image
Favorite
PT6921A image
Favorite
RoHS
RoHS RoHS compliant
Package 23-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description DC/DC Converters 3.3/2.5Vout 25W 5Vin Adj Dual Output ISR
PDF
/
Inventory: 6922
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Efficiency 75%
Voltage - Input (Max) 5.5V
Output Voltage 3.3V
Max Output Current 2.2A
Voltage - Input (Min) 4.5V
Input Voltage-Nom 5V
Current - Output (Max) 6A 2.2A
Output Power 25W
Voltage - Output 2 2.5V
Control Mode VOLTAGE-MODE
Switcher Configuration SINGLE
Isolation Non-Isolated
Number of Outputs 2
Pin Count 23
Base Part Number PT6921
Depth 32.51mm
Number of Functions 1
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 25W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 23
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series PT6920 (25W)
Packaging Tray
Operating Temperature -40°C~85°C

Dimensions

Length 67.81mm
Width 12.7mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free

Physical

Number of Pins 23
Package / Case 23-SIP Module
Mounting Type Through Hole, Right Angle
Mount Through Hole
