RoHS
RoHS RoHS compliant
Package 23-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description REGULATOR +5V TO -5.2V BB VERT
PDF
/
Inventory: 9202
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 14.2mm
Length 67.81mm

Technical

Switching Frequency-Max 600kHz
Switcher Configuration SINGLE
Output Power 12W
Output Current 3.5A
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Max Output Current 3.5A
Output Voltage -5.2V
Voltage - Input (Max) 5.5V
Efficiency 77%
Number of Outputs 1
Pin Count 23
Base Part Number PT6902
Depth 14.22mm
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 18.2W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 23
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Series PT6900 (12W)
Packaging Tray
Operating Temperature 0°C~85°C

Physical

Number of Pins 23
Package / Case 23-SIP Module
Mounting Type Through Hole
Mount Through Hole
