PT6884A
RoHS
RoHS compliant
RoHS compliantPackage 18-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 9V 5A
PDF
/
Buying Options
Total Price: USD $50.91
Unit Price: USD $50.914579
≥1 USD $50.914579
≥10 USD $48.032624
≥100 USD $45.313797
≥500 USD $42.748863
≥1000 USD $40.329117
Inventory: 1480
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 25.9mm
Length 50.55mm
Technical
Switching Frequency-Max 600kHz
Switcher Configuration SINGLE
Control Mode VOLTAGE-MODE
Output Current 5A
Input Voltage-Nom 28V
Voltage - Input (Min) 18V
Max Output Current 5A
Output Voltage 9V
Voltage - Input (Max) 36V
Efficiency 87%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 18
Base Part Number PT6884
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 45W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 18
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series Excalibur? PT6880
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 18
Package / Case 18-SIP Module
Mounting Type Through Hole, Right Angle
Mount Through Hole
