PT6882C
RoHS
RoHS compliant
RoHS compliantPackage 18-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REGULATR 2.5V 5A CU CASE HRZ SMD
PDF
/
Inventory: 5424
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 10.922mm
Technical
Switching Frequency-Max 600kHz
Switcher Configuration SINGLE
Control Mode VOLTAGE-MODE
Input Voltage-Nom 28V
Voltage - Input (Min) 15V
Max Output Current 5A
Output Voltage 2.5V
Voltage - Input (Max) 25V
Efficiency 78%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 18
Base Part Number PT6882
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) 215
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 13W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 18
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Remote On/Off
Size / Dimension 2.00Lx1.19W x 0.43 H 50.8mmx30.2mmx10.9mm
Series Excalibur? PT6880
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Package / Case 18-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
Alternative Model
