PT6726C
RoHS
/
Package 17-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REGULTR 2.5V 14A CU CASE HRZ SMD
PDF
/
Inventory: 8267
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 25.9mm
Length 65.5mm
Height 12.7mm
Technical
Switching Frequency-Max 400kHz
Switcher Configuration SINGLE
Control Mode VOLTAGE-MODE
Input Voltage-Nom 12V
Voltage - Input (Min) 10.8V
Max Output Current 14A
Output Voltage 2.5V
Voltage - Input (Max) 13.2V
Efficiency 87%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 17
Base Part Number PT6726
Reach Compliance Code unknown
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 35W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 17
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Remote On/Off, SCP
Series Excalibur? PT6725
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Package / Case 17-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
