PT6716A
RoHS
RoHS compliant
RoHS compliantPackage 17-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Switching Converters, Regulators & Controllers 2.5Vout 13A 5V-Inp CU Case Adj ISR
PDF
/
Inventory: 1672
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 25.9mm
Length 65.28mm
Technical
Switching Frequency-Max 400kHz
Switcher Configuration SINGLE
Control Mode VOLTAGE-MODE
Output Current 13A
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Max Output Current 13A
Output Voltage 2.5V
Voltage - Input (Max) 5.5V
Efficiency 88%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 17
Base Part Number PT6716
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 32.5W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 17
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series Excalibur? PT6715
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 17
Package / Case 17-SIP Module
Mounting Type Through Hole, Right Angle
Mount Through Hole
