PT6705N
RoHS
/
Package 17-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REGULATOR 3.3V 13A VADJ VERT
PDF
/
Inventory: 1754
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Height 25.908mm
Technical
Switching Frequency-Max 400kHz
Switcher Configuration SINGLE
Control Mode VOLTAGE-MODE
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Voltage - Output 1 3.3V
Max Output Current 13A
Voltage - Input (Max) 5.5V
Efficiency 91%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 17
Base Part Number PT6705
Reach Compliance Code unknown
Number of Functions 1
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 42.9W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 17
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 2.58Lx0.50W x 1.02 H 65.5mmx12.7mmx25.9mm
Series Excalibur? PT6705
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Package / Case 17-SIP Module
Mounting Type Through Hole
Mount Through Hole
