PT6703N
RoHS
RoHS compliant
RoHS compliantPackage 23-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REG SW 1.1-1.85V 13A VERT T/H
PDF
/
Inventory: 7509
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 23-SIP Module
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series Excalibur? PT6703
Size / Dimension 2.58Lx0.67W x 1.02 H 65.5mmx17.0mmx25.9mm
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 23
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Subcategory Switching Regulator or Controllers
Max Power Dissipation 24.1W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PT6703
Pin Count 23
JESD-30 Code R-XSMA-T23
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 86%
Voltage - Input (Max) 5.5V
Max Output Current 13A
Voltage - Output 1 1.1V~1.85V
Voltage - Input (Min) 3.1V
Input Voltage-Nom 3.3V
Control Mode VOLTAGE-MODE
Current - Output 1 13A
Switcher Configuration SINGLE
Switching Frequency-Max 400kHz
Dimensions
Height 25.908mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
