PT6702A
RoHS
RoHS compliant
RoHS compliantPackage 23-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REG 3.3V-1.3V-2.05V 4BIT 12A HOR
PDF
/
Inventory: 8499
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 12.7mm
Technical
Switching Frequency-Max 400kHz
Switcher Configuration SINGLE
Control Mode VOLTAGE-MODE
Input Voltage-Nom 3.3V
Voltage - Input (Min) 3.1V
Voltage - Output 1 1.3V~2.05V
Max Output Current 13A
Voltage - Input (Max) 3.6V
Efficiency 86%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-XSMA-T23
Pin Count 23
Base Part Number PT6702
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) 215
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 26.7W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 23
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 2.58Lx1.19W x 0.50 H 65.5mmx30.2mmx12.7mm
Series Excalibur? PT6701
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Package / Case 23-SIP Module
Mounting Type Through Hole, Right Angle
Mount Through Hole
