PT6672G
RoHS
RoHS compliant
RoHS compliantPackage 14-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REG 3.3V-9V 1.67A SIP HORZ HT
PDF
/
Inventory: 7874
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole, Right Angle
Package / Case 14-SIP Module
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series PT6670
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Max Power Dissipation 15W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) 215
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PT6672
Pin Count 14
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 80%
Voltage - Input (Max) 3.6V
Output Voltage 9V
Max Output Current 1.67A
Voltage - Input (Min) 3.1V
Input Voltage-Nom 3.3V
Switcher Configuration BOOST
Switching Frequency-Max 300kHz
Dimensions
Height 31mm
Length 62.5mm
Width 10.7mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
