PT6656G
RoHS
RoHS compliant
RoHS compliantPackage 14-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC Converters 12Vout 4A 24V-Input Adjustable ISR
PDF
/
Buying Options
Total Price: USD $83.93
Unit Price: USD $83.931906
≥1 USD $83.931906
≥10 USD $79.181045
≥100 USD $74.699099
≥500 USD $70.470846
≥1000 USD $66.481928
Inventory: 1152
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole, Right Angle
Package / Case 14-SIP Module
Number of Pins 14
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series PT6650
Size / Dimension 2.36Lx1.22W x 0.42 H 59.9mmx31.0mmx10.7mm
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Subcategory Switching Regulator or Controllers
Max Power Dissipation 48W
Technology HYBRID
Terminal Position SINGLE
Number of Functions 1
Terminal Pitch 2.54mm
Depth 30.98mm
Frequency 550kHz
Base Part Number PT6656
Pin Count 14
Number of Outputs 1
Output Voltage 12V
Max Output Current 4A
Voltage - Input (Min) 15V
Input Voltage-Nom 24V
Current - Output (Max) 4A
Output Current 5A
Max Output Voltage 12V
Control Mode VOLTAGE-MODE
Switcher Configuration SINGLE
Max Output Power 60W
Isolation Non-Isolated
Max Input Voltage (DC) 28V
Min Input Voltage (DC) 9V
Dimensions
Height 10.668mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
