PT6654Q
RoHS
RoHS compliant
RoHS compliantPackage 14-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Switching Converters, Regulators & Controllers 9Vout 5A 24V-Input Adjustable ISR
PDF
/
Inventory: 9645
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 10.7mm
Length 62.5mm
Height 31mm
Technical
Switching Frequency-Max 600kHz
Switcher Configuration SINGLE
Input Voltage-Nom 24V
Voltage - Input (Min) 12V
Max Output Current 5A
Output Voltage 9V
Voltage - Input (Max) 28V
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 14
Base Part Number PT6654
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 45W
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series PT6650
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Package / Case 14-SIP Module
Mounting Type Through Hole, Right Angle
Mount Through Hole
