PT6653F
RoHS
RoHS compliant
RoHS compliantPackage 14-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 5V 25W
PDF
/
Inventory: 4158
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SMD Module
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series PT6650
Size / Dimension 2.36Lx1.22W x 0.42 H 59.9mmx31.0mmx10.7mm
Feature Remote On/Off
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Max Power Dissipation 25W
Technology HYBRID
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 215
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PT6653
Pin Count 14
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 84%
Voltage - Input (Max) 28V
Output Voltage 5V
Max Output Current 5A
Voltage - Input (Min) 9V
Input Voltage-Nom 24V
Switcher Configuration SINGLE
Switching Frequency-Max 600kHz
Dimensions
Height 10.668mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
