PT6653B image
Favorite
PT6653B image
Favorite
RoHS
RoHS RoHS compliant
Package 14-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description Module DC-DC 1-OUT 5V 5A 14-Pin SIP Module
PDF
/
Inventory: 2524
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Height 10.668mm

Technical

Isolation Non-Isolated
Switching Frequency-Max 600kHz
Switcher Configuration SINGLE
Control Mode VOLTAGE-MODE
Output Current 5A
Input Voltage-Nom 24V
Voltage - Input (Min) 9V
Max Output Current 5A
Output Voltage 5V
Voltage - Input (Max) 28V
Efficiency 84%
Number of Outputs 1
Pin Count 14
Base Part Number PT6653
Depth 30.98mm
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 25W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Remote On/Off
Size / Dimension 2.36Lx1.22W x 0.42 H 59.9mmx31.0mmx10.7mm
Series PT6650
Packaging Tray
Operating Temperature -40°C~85°C

Physical

Number of Pins 14
Package / Case 14-SMD Module
Mounting Type Surface Mount
Mount Surface Mount, Through Hole
