PT6624P
RoHS
/
Package 14-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REGULATOR 12V-3.6V 7A SIP VERTIC
PDF
/
Inventory: 2092
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Height 30.988mm
Technical
Switching Frequency-Max 750kHz
Switcher Configuration SINGLE
Control Mode VOLTAGE-MODE
Input Voltage-Nom 12V
Voltage - Input (Min) 9V
Voltage - Output 1 3.6V
Max Output Current 6A
Voltage - Input (Max) 16V
Efficiency 83%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 14
Base Part Number PT6624
Number of Functions 1
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 21.6W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Size / Dimension 1.71Lx0.42W x 1.22 H 43.4mmx10.7mmx31.0mm
Series PT6620
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Package / Case 14-SIP Module
Mounting Type Through Hole
Mount Through Hole
