PT6605P
RoHS
RoHS compliant
RoHS compliantPackage 14-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 1-OUT 1.2V 7A 14-Pin SIP Module
PDF
/
Inventory: 9213
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Output Current 7A
Control Mode VOLTAGE-MODE
Current - Output 1 7A
Switcher Configuration SINGLE
Switching Frequency-Max 725kHz
Isolation Non-Isolated
Input Voltage-Nom 5V
Voltage - Input (Min) 3.1V
Max Output Current 9A
Output Voltage 1.2V
Voltage - Input (Max) 6V
Efficiency 68%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 14
Base Part Number PT6605
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 30.98mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 10.8W
Subcategory Switching Regulator or Controllers
Additional Feature 3.3V INPUT BUS CAPABLE
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Series PT6600
Packaging Tray
Operating Temperature -40°C~85°C
Dimensions
Length 43.43mm
Width 10.7mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
Physical
Number of Pins 14
Package / Case 14-SIP Module
Mounting Type Through Hole
Mount Through Hole
