PT6602M
RoHS
/
Package 14-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REGULATOR 1.5V 9A SIP CUHS TH
PDF
/
Inventory: 1754
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 10.7mm
Length 43.4mm
Height 31mm
Technical
Switching Frequency-Max 725kHz
Switcher Configuration SINGLE
Control Mode VOLTAGE-MODE
Input Voltage-Nom 5V
Voltage - Input (Min) 3.1V
Voltage - Output 1 1.5V
Max Output Current 9A
Voltage - Input (Max) 6V
Efficiency 68%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 14
Base Part Number PT6602
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 13.5W
Subcategory Switching Regulator or Controllers
Additional Feature 3.3V INPUT BUS CAPABLE
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Series PT6600
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Package / Case 14-SIP Module
Mounting Type Through Hole, Right Angle
Mount Through Hole
