PT6523P
RoHS
RoHS compliant
RoHS compliantPackage 14-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC Converters 2.5Vout 8A 5V/3.3V Inp Adj ISR
PDF
/
Inventory: 7230
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 14-SIP Module
Number of Pins 14
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series PT6520
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Subcategory Switching Regulator or Controllers
Max Power Dissipation 20W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 30.98mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PT6523
Pin Count 14
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 85%
Voltage - Input (Max) 5.5V
Output Voltage 2.5V
Max Output Current 8A
Voltage - Input (Min) 3.1V
Input Voltage-Nom 3.3V
Output Current 8A
Control Mode VOLTAGE-MODE
Switcher Configuration SINGLE
Switching Frequency-Max 400kHz
Isolation Non-Isolated
Dimensions
Length 43.43mm
Width 10.7mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
