PT6522E
RoHS
RoHS compliant
RoHS compliantPackage 14-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC Converters ADJUSTABLE ISR
PDF
/
Buying Options
Total Price: USD $34.39
Unit Price: USD $34.392269
≥1 USD $34.392269
≥10 USD $32.44554
≥100 USD $30.608998
≥500 USD $28.876417
≥1000 USD $27.2419
Inventory: 1460
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Height 10.668mm
Technical
Switching Frequency-Max 400kHz
Switcher Configuration SINGLE
Control Mode VOLTAGE-MODE
Output Current 8A
Input Voltage-Nom 3.3V
Voltage - Input (Min) 3.1V
Max Output Current 8A
Output Voltage 1.5V
Voltage - Input (Max) 5.5V
Efficiency 75%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 14
Base Part Number PT6522
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 30.73mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 12W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Remote On/Off, SCP
Size / Dimension 1.71Lx1.22W x 0.42 H 43.4mmx31.0mmx10.7mm
Series PT6520
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 14
Package / Case 14-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
