PT6522B
RoHS
RoHS compliant
RoHS compliantPackage 14-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 3.3VIN 1-OUT 1.5V 8A 14-Pin SIP Module
PDF
/
Inventory: 9786
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 10.668mm
Technical
Isolation Non-Isolated
Switching Frequency-Max 400kHz
Switcher Configuration SINGLE
Nominal Input Voltage 3.3V
Current - Output 1 8A
Control Mode VOLTAGE-MODE
Output Current 8A
Input Voltage-Nom 3.3V
Voltage - Input (Min) 3.1V
Max Output Current 8A
Output Voltage 1.5V
Voltage - Input (Max) 5.5V
Efficiency 75%
Number of Outputs 1
Pin Count 14
Base Part Number PT6522
Depth 30.98mm
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 12W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Remote On/Off, SCP
Size / Dimension 2.36Lx1.22W x 0.42 H 59.9mmx31.0mmx10.7mm
Series PT6520
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 14
Package / Case 14-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
Alternative Model
