PT6516N
RoHS
/
Package 14-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 1.8V 8A
PDF
/
Buying Options
Total Price: USD $74.38
Unit Price: USD $74.379724
≥1 USD $74.379724
≥204 USD $29.678105
≥504 USD $28.686865
≥996 USD $28.197153
Inventory: 7710
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 10.7mm
Length 43.4mm
Height 31mm
Technical
Switching Frequency-Max 725kHz
Switcher Configuration BUCK
Input Voltage-Nom 5V
Voltage - Input (Min) 3.1V
Voltage - Output 1 1.8V
Max Output Current 8A
Voltage - Input (Max) 6V
Efficiency 81%
Qualification Status Not Qualified
Number of Outputs 1
Base Part Number PT6516
Number of Functions 1
Terminal Position SINGLE
Max Power Dissipation 14.4W
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Series PT6510
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Package / Case 14-SIP Module
Mounting Type Through Hole
Mount Through Hole
