PT6516F
RoHS
/
Package 14-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 1.8V 14W
PDF
/
Inventory: 5561
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SMD Module
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series PT6510
Size / Dimension 2.36Lx1.22W x 0.42 H 59.9mmx31.0mmx10.7mm
Feature OTP, SCP
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Max Power Dissipation 14W
Terminal Position SINGLE
Terminal Form GULL WING
Number of Functions 1
Base Part Number PT6516
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 81%
Voltage - Input (Max) 6V
Max Output Current 8A
Voltage - Output 1 1.8V
Voltage - Input (Min) 3.1V
Input Voltage-Nom 5V
Switcher Configuration BUCK
Switching Frequency-Max 725kHz
Dimensions
Height 10.668mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
