PT6502G
RoHS
RoHS compliant
RoHS compliantPackage 14-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC Converters ADJUSTABLE ISR
PDF
/
Inventory: 5667
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole, Right Angle
Package / Case 14-SIP Module
Number of Pins 14
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series PT6500
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Subcategory Switching Regulator or Controllers
Max Power Dissipation 12W
Technology HYBRID
Terminal Position SINGLE
Number of Functions 1
Terminal Pitch 2.54mm
Depth 30.98mm
Base Part Number PT6502
Pin Count 14
Number of Outputs 1
Efficiency 68%
Voltage - Input (Max) 6V
Output Voltage 1.5V
Max Output Current 8A
Voltage - Input (Min) 3.1V
Input Voltage-Nom 5V
Output Current 8A
Control Mode VOLTAGE-MODE
Switcher Configuration SINGLE
Switching Frequency-Max 725kHz
Isolation Non-Isolated
Dimensions
Length 62.48mm
Width 10.7mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
