PT6502A
RoHS
RoHS compliant
RoHS compliantPackage 14-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC Converters ADJUSTABLE ISR
PDF
/
Buying Options
Total Price: USD $47.67
Unit Price: USD $47.670594
≥1 USD $47.670594
≥10 USD $44.972255
≥100 USD $42.42666
≥500 USD $40.025147
≥1000 USD $37.759574
Inventory: 5792
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole, Right Angle
Package / Case 14-SIP Module
Number of Pins 14
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series PT6500
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Subcategory Switching Regulator or Controllers
Max Power Dissipation 12W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Depth 30.73mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PT6502
Pin Count 14
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 68%
Voltage - Input (Max) 6V
Output Voltage 1.5V
Max Output Current 8A
Voltage - Input (Min) 3.1V
Input Voltage-Nom 5V
Output Current 8A
Control Mode VOLTAGE-MODE
Switcher Configuration SINGLE
Switching Frequency-Max 725kHz
Dimensions
Length 43.18mm
Width 10.7mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
