PT6475A
RoHS
RoHS compliant
RoHS compliantPackage 12-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Isolated DC/DC Converters 1.5V 14A 3.3-V Inpt Adj Step-Down ISR
PDF
/
Inventory: 6291
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 43.43mm
Technical
Switching Frequency-Max 300kHz
Switcher Configuration BUCK
Nominal Input Voltage 3.3V
Current - Output 1 14A
Control Mode VOLTAGE-MODE
Output Current 14A
Input Voltage-Nom 3.3V
Voltage - Input (Min) 2.95V
Max Output Current 14A
Output Voltage 1.5V
Voltage - Input (Max) 3.65V
Efficiency 89%
Number of Outputs 1
Pin Count 12
Base Part Number PT6475
Depth 21.21mm
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 21W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 12
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series Excalibur? PT6470
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 12
Package / Case 12-SIP Module
Mounting Type Through Hole, Right Angle
Mount Through Hole
