PT6364N
RoHS
RoHS compliant
RoHS compliantPackage 12-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC Converters 1.8V 11A 12-V Input Adj Step-Down ISR
PDF
/
Buying Options
Total Price: USD $28.86
Unit Price: USD $28.863461
≥1 USD $28.863461
≥10 USD $27.229678
≥100 USD $25.688375
≥500 USD $24.234317
≥1000 USD $22.862563
Inventory: 1462
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Width 8mm
Length 43.43mm
Technical
Isolation Non-Isolated
Switching Frequency-Max 400kHz
Switcher Configuration SINGLE
Control Mode VOLTAGE-MODE
Output Current 11A
Input Voltage-Nom 12V
Voltage - Input (Min) 10.8V
Max Output Current 11A
Output Voltage 1.8V
Voltage - Input (Max) 13.2V
Efficiency 87%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 12
Base Part Number PT6364
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Depth 12.19mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 19.8W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 18
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Series Excalibur? PT6360
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 12
Package / Case 12-SIP Module
Mounting Type Through Hole
Mount Through Hole
