RoHS
/
Package 12-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description REGULATOR 1.8V 11A 12VIN HORZ
PDF
/
Inventory: 8465
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant

Dimensions

Width 17.1mm
Length 43.4mm
Height 8mm

Technical

Switching Frequency-Max 400kHz
Switcher Configuration SINGLE
Control Mode VOLTAGE-MODE
Input Voltage-Nom 12V
Voltage - Input (Min) 10.8V
Voltage - Output 1 1.8V
Max Output Current 11A
Voltage - Input (Max) 13.2V
Efficiency 87%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 12
Base Part Number PT6364
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 19.8W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 18
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series Excalibur? PT6360
Packaging Tray
Operating Temperature -40°C~85°C

Physical

Package / Case 12-SIP Module
Mounting Type Through Hole, Right Angle
Mount Through Hole
