PT6304R
RoHS
RoHS compliant
RoHS compliantPackage 12-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 1-OUT 12V 3A 12-Pin SIP Module
PDF
/
Inventory: 3984
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 9.4mm
Length 59.7mm
Height 16.75mm
Technical
Isolation Non-Isolated
Switching Frequency-Max 550kHz
Current - Output 1 3A
Control Mode VOLTAGE-MODE
Output Power 36W
Output Current 3A
Trim/Adjustable Output YES
Voltage - Input (Min) 16V
Max Output Current 3A
Output Voltage 12V
Voltage - Input (Max) 38V
Efficiency 91%
Number of Outputs 1
Base Part Number PT6304
Depth 9.4mm
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 36W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 12
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series PT6300
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 12
Package / Case 12-SIP Module
Mounting Type Through Hole
Mount Through Hole
Alternative Model
