PT6303CT
RoHS
RoHS compliant
RoHS compliantPackage 12-SIP SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REG 3.3V 3A ADJ ON/OFF 12-SIP
PDF
/
Inventory: 8651
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 43.15mm
Technical
Isolation Non-Isolated
Switching Frequency-Max 600kHz
Switcher Configuration BUCK
Control Mode VOLTAGE-MODE
Output Current 3A
Input Voltage-Nom 10V
Voltage - Input (Min) 9V
Max Output Current 3A
Output Voltage 3.3V
Voltage - Input (Max) 26V
Efficiency 84%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 12
Base Part Number PT6303
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 16.75mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 9.9W
Subcategory Switching Regulator or Controllers
Additional Feature INPUT VOLTAGE CAN BE UPTO 38V WHEN THE INHIBIT FUNCTION IS NOT USED
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 12
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series PT6300
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 12
Package / Case 12-SIP SMD Module
Mounting Type Surface Mount
Mount Surface Mount
