PT6302BT
RoHS
RoHS compliant
RoHS compliantPackage 12-SIP SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 1-OUT 5V 3A 12-Pin SIP Module
PDF
/
Inventory: 3657
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 12-SIP SMD Module
Number of Pins 12
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series PT6300
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 12
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Subcategory Switching Regulator or Controllers
Max Power Dissipation 15W
Technology HYBRID
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Depth 16.75mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PT6302
Pin Count 12
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 89%
Voltage - Input (Max) 38V
Output Voltage 5V
Max Output Current 3A
Voltage - Input (Min) 9V
Input Voltage-Nom 9V
Output Current 3A
Control Mode VOLTAGE-MODE
Switcher Configuration BUCK
Switching Frequency-Max 600kHz
Isolation Non-Isolated
Dimensions
Length 59.7mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
